接受订货
【英文简介】
The SAM D20 Xplained Pro evaluation kit is ideal for evaluation and prototyping with the SAM D20 Cortex™-M0+ processor-based microcontrollers. Extension boards to the SAM D20 Xplained Pro can be purchased individually.
The ATSAMD20-XPRO evaluation kit does not include extension boards.
The SAM D20 Xplained Pro supports the Atmel I/O1 Xplained Pro, OLED1 Xplained Pro, and PROTO1 Xplained Pro extension boards.
Key Features
•SAMD20J18 microcontroller
•One mechanical reset button
•One mechanical user pushbutton (wake-up, bootloader entry or general purpose)
•One yellow user LED
•32.768kHz crystal
•3 Xplained Pro extension headers
•Program/debug interface for external targets
•Embedded Debugger
•Auto-ID for board identification in Atmel Studio 6.1
•One yellow status LED
•One green board power LED
•Symbolic debug of complex data types including scope information
•Programming and debugging
•Data Gateway Interface: SPI, I²C, 4 GPIOs
•Virtual COM port (CDC)
•USB powered
•Supported with application examples in Atmel Software Framework
ATMEL SAM D20 Xplained Pro开发板板载EDBG仿真器,采用Cortex-M0+内核SAMD20J18目标芯片,引出全部GPIO。EDBG板载仿真器除了可以通过SWD接口调试目标芯片外还支持USB转虚拟串口和数据Gateway的功能,更多细节请下载EDBG用户手册。
【软件资源】
例子包含在ATMEL STUDIO里面,请到ATMEL网站下载最新的STUDIO,然后参考EDBG的用户手册进行仿真调试。
【发货清单】
● SAM D20 Xplained Pro开发板一块,含板载EDBG仿真器
● 无电源,需要自备micro USB线,即常见的手机充电线
● 无光盘,资料需要从ATMEL网站下载
